YORKVILLE

PX1700

PX1700

$2,595.00 AUD
$2,595.00 AUD
Sale Sold out
Shipping calculated at checkout.

Amplifiers 2 x 850 Watt Power Amplifier

Features

  • Easily Drives Reactive Loads
  • Delivers 1700 Watts Bridged Mono @ 4 ohms
  • 850 Watts PRE Channel @ 2 ohms
  • Efficient Front-to-Back Cooling Scheme
  • Recessed Front Panel Gain Controls
  • Advanced Protection Schemes
  • Front Panel Power, Protect, Activity and Clip LED's
  • Speakon™ and Binding Post Outputs
  • Balanced XLR & ¼-inch TRS Inputs
  • Sturdy All-Steel Construction

Specifications

Amplifier class Class-H
Continuous Average Power @ 8 Ohms BCD (Watts) 400
Continuous Average Power @ 4 Ohms BCD (Watts) 600
Continuous Average Power @ 2 Ohms BCD (Watts) 850
Continuous Average Power Bridged BCD (Watts) 1700
Burst Average Power @ 8 Ohms BCD(Watts) 600
Burst Average Power @ 4 Ohms BCD (Watts) 1000
Burst Average Power @ 2 Ohms BCD (Watts) 850
Burst Average Power Bridged BCD (Watts) 1700
Frequency Response (Hz, +/- 1dB) 30Hz to 20kHz
Hum and Noise (un / Aweighted -dB) -100dB
THD -1kHz- 4 OHMS 0.0003
THD - 20Hz-20kHz, 4 Ohms 0.001
Damping Factor (30 Hz - 400 Hz @ 8 Ohms) Greater than 300
Crosstalk (1kHz / 20Hz-20kHz) -75dB / -60dB
Input Impedance - Bal/Unbal (Ohms) 30kOhms/15kOhms
Input Sensitivity (Vrms) For Full Power Out 1.4
Max Voltage Gain (dB) 31dB
Stereo / Mono / Bridge )S/M/B) Yes
Protection DC/Load/Thermal
Limiter Defeatable
High Pass Filter No
Cooling Fan
Cooling Path Front to Back
Inputs - XLR Yes (x2)
Inputs - 1/4" Jacks Yes (x2)
Outputs - Speakon 4-pin Yes
Outputs - Binding Post Yes
Power Consumption (typ/max) 700/1500
Rack Spaces Two
Transformer Type Toroidal
Exterior Finish Black Paint
Dimensions (DWH /D fm ears, inches) 16 x 19 x 3.5
Dimensions (DWH /D fm ears, cm) 40.6 x 48.3 x 8.9
Weight (lbs / kg) 35/16
